Google Tag Manager ​

These instructions are designed for tag implementation through Google Tag Manager.

Page Load Tag ​

This tag keeps track of general site visitor traffic, and is placed on every page of the site EXCEPT conversion pages.

  1. Conversion Trigger

    • Choose Triggers from left menu > New > Name trigger ‘Conversion Trigger’
    • Choose DOM Ready trigger type from list > Some DOM Ready Events
    • First Dropdown: Page Path > Second Dropdown: Contains > Insert conversion URL path that displays on your site (/thank-you, /order-confirmation, /checkout-complete, etc.).

  2. Loader Tag
    For our tag to run successfully and collect everything it needs, we can start by creating a loader tag.

    • Choose Tags from left menu > New > Name tag 'Loader Tag'
    • Choose Custom HTML from list
    • Insert the following snippet into the HTML box
    • Set trigger to All Pages on Page View
    javascript
     <script type="text/javascript" src="https://cdn.datasteam.io/js/datasteampx.js" defer async></script>

  3. Page Load Tag

    • Choose Tags from left menu > New > Name tag ‘Page Load Tag’
    • Choose Custom HTML from list
    • Insert the following code snippet into the HTML box
    • Update Access Key placeholder, leaving single quotes intact (Your_Access_Key).
      Ex.) AccessKey: ‘000000000000’
    • Choose All Pages on Page View from trigger list
    • Click Add Exception > Choose the trigger you created above (conversion trigger)
    javascript
    <script defer async>
MGX = typeof MGX === 'undefined' ? [] : MGX;
MGX.push({
  AccessKey: 'Your_Access_key'
});
</script>

Conversion Tag ​

This tag records when a user completes a conversion on the site. This can come in the form of a purchase, form submitted, etc.

A conversion page is the final confirmation/ checkout complete/ thank you page that displays after a user has completed a conversion action on the site.

  • Choose Tags from left menu > New > Name tag ‘Conversion Tag’
  • Choose Custom HTML from list
  • Insert the following code snippet into the HTML box
    javascript
    <script>
MGX = typeof MGX === 'undefined' ? [] : MGX;
MGX.push({
  AccessKey: 'Your_Access_Key', //Must be set in MGX object or passed with commit
  Label: 'Conversion',
  Info: 'Order', //Optional piece of meta data to enable classification of different conversion types/events.
  OrderId: '{{gtmOrderIdVariable}}',
  OrderTotal: '{{gtmOrderTotalVariable}}'
});
</script>
  • Update access key placeholder (Your_Access_Key), leaving single quotes intact.
    Ex.) AccessKey: ‘000000000000’
  • Update OrderId and OrderTotal placeholders ( '{{ }}' ) with the order variables you created to track these, leaving single quotes intact
    • If order values are not needed, please input null with NO quotes
      • OrderId: null,
      • OrderTotal: null
  • Set trigger to the conversion trigger you created above (conversion trigger)
